Network Video Recorders with NVIDIA Jetson

The Advantech range of AI network video recorders (NVR) make surveillance in any environment both efficient and simple with a single box solution both capturing the images and performing AI inference. Perfect for solutions such as premises surveillance, smart city traffic monitoring or warehouse logistic operations.

Given the Jetson embedded GPU’s powerful performance, the MIC-7x0IVA range of NVRs provide a cost-effective AI NVR solution for a wide range of applications. They support 8-channel 1080p30 decoding, encoding and AI inference computing. With eight PoE LAN ports, IP cameras can be easily deployed. tThe products have storage space for eight channels of 24/7 video recording for up to 30 days, and also support hot-swappable 2.5" HDD trays. These highly integrated systems enable AI application developers to rapidly develop and deploy unique AI solutions in a variety of environments.

Key Key 1

NVR based on NVIDIA Jetson AGX

The Advantech MIC-730IVA Network Video Recorder is powered by the NVIDIA Jetson Xavier AGX platform, providing all the performance of GPU workstations, but in an embedded module format. Featuring strict validation to ensure thermal, mechanical, and electrical compatibility, plus industrial-grade anti-vibration, high temperature operation capabilities - all in a modular, compact design. The MIC-730IVA is a perfect high-end NVR.

Configure Now
MIC-730IVA
Specification MIC-710IVA MIC-710IVX MIC-730IVA
Technology Jetson Nano Jetson Xavier NX Jetson AGX
Processor ARM A57, 4C7 ARM v8.2, 6C ARM v8.2, 8C
Graphics Maxwell 128 CUDA Cores 384 CUDA cores and 48 Tensor cores + 2NVDLA Volta 512 NVIDIA CUDA cores 64 Tensor Cores
Memory 4GB LPDDR4 8GB LPDDR4 16GB LPDDR4
Flash 16GB eMMC 5.1 16GB eMMC 5.1 32GB eMMC 5.1
Ethernet 10/100/1000 Mbps RJ45 x1 10/100/1000 Mbps RJ45 x1 10/100/1000 Mbps RJ45 x1
Camera POE 10/100 Mbps IEEE 802.3af x8 10/100 Mbps IEEE 802.3af x8 10/100 Mbps IEEE 802.3af x8
Display HDMI x1 (Max 2160p @ 60Hz) HDMI x1 (Max 2160p @ 60Hz) HDMI x1 (Max 2160p @ 60Hz)
USB 1x USB 2.0 Internal, 2x USB 3.0 1x USB 2.0 Internal, 2x USB 3.0 1x USB 2.0 Internal, 2x USB 3.0
Storage Internal 3.5” HDD bay x2 Internal 3.5” HDD bay x2 Internal 3.5” HDD bay x2
DI/DO 8 bit (4in/4out) 8 bit (4in/4out) 8 bit (4in/4out)
Power Type AC 100-240V 250W ATX AC 100-240V 250W ATX AC 100-240V 250W ATX
Temperature 0C - +40C 0C - +40C 0C - +40C
Dimensions 300x330x57 (WxDxHmm) 300x330x57 (WxDxHmm) 300x330x57 (WxDxHmm)
Weight 3KG 3KG 3KG
OS Ubuntu 18.04 Ubuntu 18.04 Ubuntu 18.04
Certifications CE/FCC CE/FCC CE/FCC
